Mahindra RoadMaster G80
If you are working on road construction, land development, or infrastructure projects, choosing the right motor grader can directly impact your productivity and project cost. The Mahindra RoadMaster G80 is one of the most efficient, reliable and budget-friendly motor graders designed specially for Indian conditions. The Mahindra Motor Grader G80 is built to handle diverse project requirements with ease.
At Perfect Power Equipment, we provide complete solutions for Mahindra motor graders. We are a trusted Mahindra RoadMaster G80 supplier and also known as a reliable Mahindra RoadMaster G80 dealer in Delhi NCR, offering sales, rental and repair services across Delhi NCR.
Product Overview
The Mahindra Motor Grader G80 is developed after deep research on Indian road conditions. With over 20,000+ days of product development and 6000+ hours of testing, this machine is built to deliver consistent performance in real working environments.
In India, most road projects are related to rural development, expansion and semi-urban infrastructure. The G80 is specially designed for these types of applications where efficiency, fuel savings and low maintenance matter the most. This makes the Mahindra RoadMaster G80 one of the most practical and value-for-money graders in its category.
Specification
Engine
| Model | G80 D | |
| Form of Air Aspiration | Turbo Charged | |
| No of Cylinders | 4 | |
| Bore | 96mm | |
| Stroke | 122 mm | |
| Displacement | 3532 cc | |
| High idle rpm | 2150+/-50 rpm | |
| Low ideal rpm | 850+/-50 rpm | |
| Cooling system | Water cooled | |
| Type of fuel | Diesel | |
| Gross horse power | 55 kW (74hp) @ 1950 rpm | |
| Peak gross torque | 400 Nm@ 1100-1200 rpm | |
| Electrical system voltage | 12 V | |
Operating Specification
| Gross vehicle weight | 7738 | |
| FAW | 3196 | |
| RAW | 4542 | |
| Speed @ gear (kmph) | Forward | Reverse |
| 1st | 4.5 to 5.5 | 5.0 to 6.5 |
| 2nd | 6.5 to 8.0 | 8.0 to 9.5 |
| 3rd | 14.5 to 16.5 | |
| 4th | 29.0 to 32.5 | |
| Turning radius outside tyre R1 | 10 m | |
| Steering angle inner wheel | 45° | |
| Steering angle outer wheel | 32° | |
Moldboard
| Base Length of MB | 3000 mm | |
| Thickness of Moldboard | 16 mm | |
| Blade Height | H19 | 516 mm |
Cutting Edge (Blade)
| Standard Length of Cutting Edge | WB | 2600 mm {3 piece cutting edge} {1100 + 1100 + 400} |
| Standard length of cutting edge with side extension | WB* | 3000 mm {4 piece cutting edge} {1100 + 1100 + 400+ 400} |
| Width of Cutting Edge | 152 mm | |
| Thickness of Cutting Edge | 16 mm |
Dimensions (IN MM)
| Wheel Base | L3 | 5050 mm |
| Distance- Front axle to Moldboard Blade base | L12 | 1691 mm |
| Transport length | L1 | 7360 mm |
| Minimum Ground Clearance | H4 | 386 mm |
| Max vehicle height | H1 | 3300 mm |
| Track width- Front | W3F | 1674 mm |
| Track Width Rear | W3R | 1739 mm |
| Width- outside front tires | W1F | 2021 mm |
| Width- outside rear tires | W1R | 2207 mm |
Blade Range
| Circle rotation angle | AB | 500 from transverse of vehicle | |
| Circle drive | Hydraulic cylinders with no end mechanical stoppers | ||
| Blade side shift (LH/ RH) | W15 | 513 mm | |
| Blade tilt angle/ Bank cut angle (LH/RH) at ground level measured on blade | A9 | 200 / 150] | |
| Blade tilt angle/ Bank cut angle (LH/RH) at ground level measured on drawbar | A9’ | [25.60 / 200] | |
| Blade pitch angle at ground line | A11 | Forward 400 Backward 50 | |
| Blade without extension outside front tyre with blade positioned parallel to wheel axis | W9 | 289.5mm | |
| Blade outside front tyre with blade positioned parallel to wheel axis | ‘W9 | 489.5mm | |
| Blade lift at normal blade pitch angle | H20 | 395 mm | |
| Max blade cut depth below ground at nominal blade angle | D | 300 mm | |
| Attachment oscillation angle | E | Upward 10 0 Downward 15 0 | |
End Bit
| Width | C | 200 mm |
| Thickness | 16 mm | |
| Blade Pull force (Kgs ) | 27 kN | |
| Blade Down force (Kgs) | 27 kN |
Front Axle
| Type | Non Driven, Steerable, Central Pivoted |
Rear Axle
| Type | Driven, Non Steerable, Rigid |
Tyres and Wheels
| Front Tyre | 13 x 24-12 PR |
| Rear Tyre | 17.5 x 25-16PR |
Tyre Pressure
| Front / Rear | 304kPa |
Transmission
| Model Name | Carraro 4WD Transmission |
| Gear Ratios | Forward / Reverse |
| 1st | 5.603 / 4.643 |
| 2nd | 3.481 / 2.884 |
| 3rd | 1.585 / 1.313 |
| 4th | 0.793 / 0.657 |
Hydraulics
| System | Open Centre |
| Pump Type | Fixed Displacement Tandem Gear Pump 26+26 cm3 (cubic centimetre) |
| Max Pump Flow rate | 96 lpm @ 1950 rpm |
| Max Working pressure | 210 bar |
| Refill qty | 50 litres |
| System Capacity | 70 litres |
| Other Feature | Load Holding with pressure refill valves for lift and sensing cylinder |
Service Capacities
| Hydraulic tank | 50 litre |
| Fuel tank | 100 litre |
| Engine coolant | 17 litre |
| Engine oil | 13.5 litres |
| Transmission | 16 litre |
| Middle axle or Rear axle (Differential) | 14.5 litre for each axle |
| Middle Axle or Rear Axle (Final Drive) | 1.5 litre (On each wheel end) |
Brakes
| Service Brake type | Foot operated hydraulically actuated oil immersed disc in middle axle |
| Parking brake type | Hand operated, mechanically,Parking Brake type actuated Caliper Brakes on middle axle |
Steering
| Type | Power Steering |
| steering Valve | Load sensing with priority valve 200 cm3 (cubic centimeter) |
| Other feature | Emergency steering in case of pump failure |
Electrical
| System Voltage | 12 V |
| Battery Rating | 12 V, 100 AH |
| Alternator type | 12 V, 90 amphere |
Disclaimer
- Technical specifications, features are subjected to change without prior notice. Image used are for representative purposes only.
- Accessories shown may not be a part of the standard product. Actual colours may vary. E & O.E.
- All dimensions are variable within +/- 5% Standard Exclusions Apply. For further details on the warranty, please contact your dealer.
Mahindra RoadMaster G80 for Sale
If you are planning to invest in a motor grader, the Mahindra Motor Grader G80 is a smart and long-term solution. It offers the perfect balance of performance, cost and durability. We are a trusted supplier providing genuine Mahindra machines with full support. We are also known as a reliable RoadMaster G90 dealer and RoadMaster G100 supplier, giving you multiple options based on your project scale.
Key Advantages:
- Low fuel consumption (approx. 7–8 litres/hour)
- Lowest maintenance cost in its segment
- Strong and reliable Mahindra engine
- Easy to operate and maintain
- Ideal for all types of projects
Features
Hydraulic System
Advanced hydraulic system with up to 20 MPa pressure ensures powerful blade performance. The 26+26 cm³ gear pump delivers faster operation and higher productivity.
Blade Range
50° blade rotation allows quick and efficient grading in heavy materials. Smart blade design ensures smooth movement between tyres during operation.
Differential Lock
100% mechanical differential lock provides better traction and equal power distribution, ensuring strong performance on muddy and uneven surfaces.
Comfort & Control
Ergonomic cabin with easy-to-reach controls and comfortable seating ensures fatigue-free operation during long working hours.
Applications of Mahindra Motor Grader G80
If your work involves regular grading and leveling, this machine delivers consistent and reliable output. The Mahindra Motor Grader G80 is widely used for:
- Rural road construction (PMGSY projects)
- District and village roads
- Land leveling and development
- Internal roads for housing and commercial projects
Mahindra RoadMaster G80 Price
The Mahindra RoadMaster G80 price stands out as a budget-friendly option while still delivering reliable and efficient performance. It is a smart investment for contractors and businesses due to its low initial purchase cost, lowest operating cost in its segment and fuel-efficient performance. Additionally, the machine requires minimal maintenance and offers high resale value, ensuring better long-term returns.
Why Buy From Perfect Power Equipment?
We are not just a seller — we help you choose the right machine based on your project.
What You Get:
- Genuine Mahindra equipment
- Competitive pricing
- Expert consultation
- Fast delivery
- Strong after-sales support
- Spare parts availability
Mahindra RoadMaster G80 on Rent
If you need a motor grader for a short-term project or want to avoid heavy investment, choosing the Mahindra RoadMaster G80 on rent is a smart and cost-effective option. It allows you to complete your work efficiently without the burden of purchasing a new machine.
At Perfect Power Equipment, we provide well-maintained and ready-to-use G80 graders on rent, ensuring smooth performance and reliable support for your project.
Our rental solutions are designed to suit different project needs — whether it’s road construction, land leveling, or infrastructure work. The G80 offers excellent fuel efficiency, easy operation and consistent performance, making it ideal for both small and mid-scale projects. We ensure quick delivery, proper machine inspection and full support during the rental period so that your work continues without any delays or interruptions.
Benefits of Renting:
- No heavy investment
- Flexible rental duration
- Ready-to-use machines
- Well-maintained equipment
- No maintenance or repair cost burden
- Latest and properly serviced machines
- Quick availability for urgent projects
- Reduced operational risk
- Ideal for short-term and project-based needs
- Expert support and assistance during the rental period
Mahindra RoadMaster G80 Repair Services
We provide reliable and professional Mahindra RoadMaster G80 repair services in Delhi NCR to keep your machine running at peak performance. Our expert technicians carry out quick fault diagnosis and use genuine spare parts to ensure durable and efficient repairs.
We also offer complete Mahindra RoadMaster G80 services, ensuring your equipment performs consistently in all working conditions. Our Mahindra RoadMaster are designed to minimize downtime and maximize productivity.
Our Services Include:
- Engine repair
- Hydraulic maintenance
- Blade and control system repair
- Electrical troubleshooting
- Spare parts replacement (genuine parts)
- On-site repair and emergency support
- Complete machine inspection and diagnostics
- Oil change and lubrication services
Complete Mahindra RoadMaster G80 Solution in One Place
At Perfect Power Equipment, we offer complete solutions centered around the Mahindra RoadMaster G80, ensuring you get everything you need in one place — from purchase to long-term support. Whether you are looking to buy, rent, or maintain your motor grader, our team provides end-to-end assistance tailored to your project requirements.
The Mahindra RoadMaster G80 is a perfect combination of performance, efficiency and affordability, making it an ideal choice for contractors, infrastructure projects and construction businesses. Backed by our expert support, genuine parts and prompt service, you can rely on consistent performance and minimal downtime.
If you are searching for a dependable, cost-effective and high-performance motor grader, the G80 stands out as the right investment for your business growth.
Contact us to get the best price and complete sales, rental and repair support for Mahindra RoadMaster G80 in Delhi NCR.
